Technical Specifications

FRAME
XDS Carbon Frame, Toray T800

FORK
XDS Carbon Fork, Toray T700, 100 × 12 mm Thru-Axle

HANDLEBAR / STEM
Branta Carbon Integrated Handlebar and Stem

SEATPOST
XDS Carbon Aero Seatpost

REAR DERAILLEUR
Shimano 105 Di2 RD-R7150

FRONT DERAILLEUR
Shimano 105 Di2 FD-R7150

SHIFTERS
Shimano 105 Di2 ST-R7170

BRAKES
Shimano 105 BR-R7170

CASSETTE
Shimano 105 CS-R7101, 11–34T

CRANKSET
Branta Aluminum Power Meter Crankset, 52/36T, 24 mm Steel Spindle, with Apple Find My Anti-Theft Technology

BOTTOM BRACKET
BSA 24 mm

BRAKE ROTORS
Shimano SM-RT70, Front: 160 mm / Rear: 140 mm

CHAIN
Shimano CN-M7100

WHEELSET
Branta C45 Base, Stainless Steel Spokes

TIRES
Branta R301, 700 × 30C, 60 TPI
Maximum Tire Clearance: 32C

SADDLE
Branta R302, Steel Rails

WEIGHT
8.49 kg / 18.67 lbs (Size Large)

AVAILABLE SIZES
XS / S / M / L / XL / XXL

Additional Sizes & Colors Available

Looking for a different size or color? Contact Bicycle House for additional availability and ordering options.

Phone: (513) 847-1986
Email: [email protected]

Specifications, components, pricing, and availability are subject to change without notice.
