Specifications

Frame
Scale Carbon HMF
• Adjustable head angle
• Syncros Cable Integration System
• Advanced Shock & Standing Damping System
• BB92, UDH Interface
• 12×148mm Boost rear spacing, 55mm chainline

Fork
Scale Rigid HMF Carbon
• Post Mount Disc Standard
• Tapered carbon steerer

Rear Derailleur
SRAM S1000 Eagle AXS Transmission
• 12-speed wireless electronic shifting

Shifters
SRAM AXS Pod Controller

Crankset
SRAM Eagle 70 Transmission
• DUB
• 55mm chainline
• 34T chainring

Chainguide
SCOTT Custom

Bottom Bracket
SRAM DUB PF92 MTB Wide
• Shell size: 41×92mm

Chain
SRAM Eagle 70 Transmission

Cassette
SRAM Eagle XS-1270 V2 Transmission
• 10–52T

Brakes
SRAM DB6 Hydraulic Disc Brakes
• 4-piston

Rotors
SRAM Centerline CL
• 180mm Front / 160mm Rear

Handlebar
Syncros Fraser 2.0 XC Alloy 6061 D.B.
• Flat bar, 8° sweep
• 740mm width
• Syncros Performance XC lock-on grips

Stem
Syncros XC 2.0
• Syncros Cable Integration System
• -12° rise
• 31.8mm clamp
• 1 1/8" steerer

Seatpost
Syncros Duncan 2.0
• 10mm offset
• 31.6 × 400mm

Saddle
Syncros Belcarra V2.0 Cut Out
• CrMo rails

Headset
Syncros / Acros Angle Adjust & Cable Routing System
• ±0.6° head angle adjustment
• ZS56/28.6 – ZS56/40 MTB

Front Hub
Formula CL-811
• 15×110mm

Rear Hub
Formula CL-3248
• 12×148mm

Spokes
Stainless steel, black
• 15G, 1.8mm

Rims
Syncros X-28
• 28H
• Tubeless Ready

Front Tire
Maxxis Aspen
• 29×2.4"
• 120 TPI
• Tubeless Ready, EXO casing

Rear Tire
Maxxis Aspen
• 29×2.4"
• 120 TPI
• Tubeless Ready, EXO casing

Extras
SRAM AXS PowerPack

Accessories
Spirgrips+ Inner Bar Ends

Weight

Approx. Weight
• 10.5 kg (Tubeless setup)
• 23.15 lbs (Tubeless setup)

Maximum System Weight
120 kg
(Includes bike, rider, equipment, and any additional luggage)
