Specifications

Frame

• Genius Carbon HMF Mainframe with Alloy 6061 Swingarm

• Integrated Suspension Technology

• Virtual 4-Link Kinematic / Adjustable Head Angle

• Syncros Cable Integration System

• BB92 / UDH Interface / 12x148mm with 55mm Chainline

Fork

• Ohlins RXF36 m.2 Air

• TTX-Technology HSC / LSC / LSR Adjustable

• 15x110mm Axle, 44mm Offset, Tapered Steerer

• 160mm Travel

Rear Shock

• FOX FLOAT X NUDE PE EVOL Piggy Back Trunnion

• SCOTT Custom with Travel / Geometry Adjustment

• 3 Modes: Climb – Traction Control – Descend

• Custom Large Air Volume / Compression & Rebound Adjustable

• Travel: 150–100–Climb / T185x55mm

Remote System

• TracLoc Technology

• Rear Suspension & Dropper Remote

• 3 Rear Suspension Modes

Drivetrain

• Rear Derailleur: SRAM GX Eagle AXS Transmission, 12 Speed, Wireless

• Shifters: SRAM GX Eagle AXS Rocker Controller

• Crankset: SRAM GX Eagle Transmission, Bash Guard, DUB, 55mm CL, 32T

• Chainguide: SCOTT Custom

• Bottom Bracket: SRAM DUB PF 92 MTB Wide, Shell 41x92mm

• Chain: SRAM CN GX Eagle Transmission

• Cassette: SRAM GX Eagle XS 1275 Transmission, 10–52T

Brakes

• Shimano XT M8120, 4 Piston Disc

• Rotors: Shimano SM-RT76, 6 Bolt (203mm Front / 180mm Rear)

Cockpit

• Handlebar: Syncros Hixon iC Carbon

  • S & M: 15mm Rise / L & XL: 25mm Rise

  • 8° Back Sweep / 780mm Width

• Grips: Syncros Endurance Lock-On

• Headset: Syncros–Acros Angle Adjust & Cable Routing HS System

  • ±0.6° Head Angle Adjustment

  • ZS56/28.6 – ZS56/40 MTB

Seatpost & Saddle

• Seatpost: Syncros Duncan Dropper Post 1.5S, Travel Adjust, 31.6mm

  • S: 140mm / M & L: 170mm / XL: 200mm

• Saddle: Syncros Tofino 2.0 Regular, CRMO Rails

Wheelset & Tires

• Wheels: Syncros Revelstoke 2.0, 6 Bolt

  • Front: 15x110mm / Rear: 12x148mm

  • 30mm Tubeless Ready Rim, 28H, XD Driver

  • Syncros Axle with Removable Lever (6mm Allen / T30 / T25 Tools)

• Front Tire: Maxxis Minion DHF, 29x2.6", 120TPI, Tubeless Ready, EXO 3C MaxxTerra

• Rear Tire: Maxxis Dissector, 29x2.6", 60TPI, Tubeless Ready, EXO 3C MaxxTerra

Extras

• SRAM AXS Powerpack

Weight

• Approx: 14.4kg / 31.75lbs (Tubeless Setup)

• Max System Weight: 128kg (bike + rider + gear + luggage)
