Product Specifications

Frame
Synapse Carbon, Proportional Response construction, integrated cable routing, downtube Stashport, 12x142mm thru-axle, UDH, BSA 68mm threaded bottom bracket, flat-mount disc, integrated seat binder, SmartSense Gen 2.0 compatible, fender mounts

Fork
Synapse Carbon, integrated crown race, 12x100mm thru-axle, flat-mount disc, internal routing, 1-1/8" to 1-1/5" Delta steerer, 55mm offset, fender mounts

Rims
DT Swiss R470 DB, 28h

Hubs
Front: Shimano RS470, 12x100mm, Center Lock
Rear: Shimano RS470, 12x142mm, Center Lock

Spokes
Stainless steel, 14g

Tires
Vittoria Zaffiro Pro V, 700x32c

Pedals
Not included

Crankset
Shimano 105 R7100, 50/34T
165mm (44cm)
170mm (48–51cm)
172.5mm (54–56cm)
175mm (58–61cm)

Bottom Bracket
Shimano BSA 68mm

Chain
Shimano 105 R7100, 12-speed

Cassette
Shimano 105 R7100, 11-36T, 12-speed

Front Derailleur
Shimano 105 R7100, braze-on

Rear Derailleur
Shimano 105 R7100

Shifters
Shimano 105 R7100, 12-speed

Handlebar
Vision Trimax Aero Alloy
400mm (44–51cm)
420mm (54–61cm)

Bar Tape
Cannondale Bar Tape, 3.5mm

Stem
Cannondale C1 Conceal, alloy, 31.8mm, -6°
80mm (44–48cm)
90mm (51cm)
100mm (54–56cm)
110mm (58–61cm)

Headset
Integrated, 1-1/8" to 1-1/2"

Brakes
Shimano 105 R7170 hydraulic disc brakes, 160/160mm RT70 rotors

Saddle
Fizik Terra Argo X7, 150mm

Seatpost
HollowGram 27, alloy, 2-bolt clamp, 330mm, 15mm offset

Sizes
44, 48, 51, 54, 56, 58, 61

Extras
Large StashBag downtube storage bag and Conceal Stem accessory/computer mount compatible with Garmin and Wahoo.
